Eco Friendly Wholesale Outdoor Galvanized 3D Fence Mesh Wire Fence Panels

Place of Origin Hebei, China
Brand Name YMWY
Certification ISO9001
Model Number 02
Minimum Order Quantity 50sets
Price usd18-usd26
Packaging Details Pallet
Delivery Time 20-60days
Payment Terms L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability 1000 Piece/sets per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Height 1.23, 1.53, 1.73, 2.03, 2.23, 2.43, 3.03m Material Galvanized Steel Wire
Surface Treatment Galvanized 、Powder Coated Or PVC Coated Width 2.50m, 2.75m, 3.0m
Wire Thickness 4.0mm,4.5mm,5.0mm Length 2.0m-2.5m
Mesh 50x200mm, 50x150mm, 50x100mm Color Customized
Post Type Square Post
Leave a Message
Product Description

CURVY WELDING MESH FENCING

Product Description

curvy fence panels, which can also be referred to as 3D fencing. These panels are typically constructed using stainless steel or carbon steel wires. Here's an overview of the process and characteristics you mentioned:

  1. Panel Construction: The wires are welded together to form a panel, creating a mesh-like structure. This panel serves as the foundation for the curvy fence.

  2. Bending Process: Using a bending machine, the wires on the short side of the rectangular-shaped panel are bent, resulting in V-shaped curves. The number of curves depends on the height of the welded wire panel.

  3. Triangle Stability: The V-shaped curves provide additional strength and rigidity to the fence panel by utilizing the principle of triangle stability. This enhances the overall durability and stability of the fence.

  4. Installation Flexibility: Curvy fence panels can be installed on flat areas as well as slopes, making them suitable for various terrains. They can be used on different types of land surfaces, including general land or even sandy areas.

Curvy or 3D fence panels offer a visually appealing and unique design compared to traditional flat fences. The combination of the curvy shape, along with the materials used, provides an attractive and sturdy fencing solution.

SHS post is the most popular post for welded mesh fence. It includes welded mesh panels, steel post and the accessories. We use good quality low carbon steel wire or galvanized wire do the welding, then make several curves based on the height of the panels to make the panel rigid and strong. Normally there will be 3cm spike wire left at the top of the panels to make the fence jump over proof as well as good looking. For the surface treatment of the panels we use electrostatic spray or PVC dipped coating. For the post, we use galvanized then do electrostatic spray.

Eco Friendly Wholesale Outdoor Galvanized 3D Fence Mesh Wire Fence Panels 0

Features:
• Easy Installation
• Cost effective
• Nice looking
• Different options on color according to the using environment
• Strong anti rust and anti corrosion ability
• Different options of install clips such as metal or plastic

Product Specification

Panel

Width : 2.50m, 2.75m, 3.0m
Height: 1.23, 1.53, 1.73, 2.03, 2.23, 2.43, 3.03m
Mesh: 50x200mm, 50x150mm, 50x100mm
Wire thickness: 4.0mm,4.5mm,5.0mm
Rigid V: 2, 3, 3, 4, 4, 4, 6
Finish: PRE-EDG+PP, PRE-HDG+PP, PRE-GALFAN+PP, HDG, HDG+PP
Nos. of brackets 2, 3, 3, 4, 4, 4, 6





Post

Section : SHS
Section size: 50x50, 60x60mm
Height: According to the panel height
Wall thickness: 1.5/2.0/2.5 mm
Finish: PRE-HDG+PP, HDG, HDG+PP



Eco Friendly Wholesale Outdoor Galvanized 3D Fence Mesh Wire Fence Panels 1Eco Friendly Wholesale Outdoor Galvanized 3D Fence Mesh Wire Fence Panels 2



Fence application

Product Application:
1.Muticonstructions, such as properties, companies, gardens, house, etc.
2.Field,such as airoprt, playground, boundary, anti intruder.
3.Protection, such as highway, railway, bridge, etc.
4.Shipping Port Security fencing, Prison security fencing, etc.

Eco Friendly Wholesale Outdoor Galvanized 3D Fence Mesh Wire Fence Panels 3

Eco Friendly Wholesale Outdoor Galvanized 3D Fence Mesh Wire Fence Panels 4



Company profile

Anping Yuanmai Wire Mesh Products Co., Ltd. is a professional manufacturer of wire mesh fence, located in Anping County, which is called “the Native land of Wire Mesh” in China. Tailong supplies quality fence and related products for a variety of applications. Our technological expertise and commitment to providing our customers with consistent quality fencing products enable us to become a long term partner for your business.
