Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post

Place of Origin Hebei, China
Brand Name YMWY
Certification ISO9001
Model Number 02
Minimum Order Quantity 50sets
Price usd18-usd26
Packaging Details Pallet
Delivery Time 20-60days
Payment Terms L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability 1000 Piece/sets per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Color Customed Size 6' High X 8' Wide Or Required Size
Post 50x50mm 60x60mm Etc Height 1.2m; 1.5m; 1.8m; 2m; 2.2m; 2.5m Etc
Material Low-Carbon Iron Wire, Galvanized Iron Wire Surface Treatment Galvanized 、Powder Coated Or PVC Coated
Width 2.2 M 2.5 M Etc Wire Thickness 4.0mm,4.5mm,5.0mm
Length 2.0m-2.5m Mesh 50x200mm, 50x150mm, 50x100mm
High Light

4.0mm 3d wire mesh fence


50x50mm Post 3d wire mesh fence


commercial 3d curved wire mesh fence

Leave a Message
Product Description


Product Description

The welded mesh fence is a mesh fence made of electric welding technology, which is durable and has good protection performance.The welded wire mesh fence is made of high-strength galvanized steel wire, welded by electric welding process, the welding point is stronger, the mesh surface is smooth and strong, and it is not easy to deform and break.

SHS post is the most popular post for welded mesh fence. It includes welded mesh panels, steel post and the accessories. We use good quality low carbon steel wire or galvanized wire do the welding, then make several curves based on the height of the panels to make the panel rigid and strong. Normally there will be 3cm spike wire left at the top of the panels to make the fence jump over proof as well as good looking. For the surface treatment of the panels we use electrostatic spray or PVC dipped coating. For the post, we use galvanized then do electrostatic spray.

Surface Treatment: The panels undergo surface treatment to improve their durability and appearance. Options for surface treatment include electrostatic spray or PVC dipped coating. This helps protect against corrosion and extends the life of the fence.

Appropriate bending, creates the unique aesthetic effect of this product, and the surface uses a variety of colors of plastic treatment, such as yellow, green, red, column and mesh of different colors is pleasing to the eye, at the same time, this product is mostly used with chassis column, installation only need to play the expansion bolt, very fast.

Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post 0


• Easy Installation
• Cost effective
• Nice looking
• Different options on color according to the using environment
• Strong anti rust and anti corrosion ability
• Different options of install clips such as metal or plastic

Packaging and shipping
1.Fence panel: plastic film / wooden case + metal/wooden pallet.

2.Fence post: plastic bag +metal/wooden pallet (with rainhat installed).
3.Fence accessories: plastic bag + carton box (clips & screws).

Product Specification

The fence panels are fully welded and 100% hot dip galvanized offering great strength, protection against corrosion and an increadibly long product life.

YUANMAI FENCING is a professional fence customizing factory with experience of more than 20 years. We provide high quality fence with affordable price, as well as provide trade assurance to ensure that your order be no risk.


Width : 2.50m, 2.75m, 3.0m
Height: 1.23, 1.53, 1.73, 2.03, 2.23, 2.43, 3.03m
Mesh: 50x200mm, 50x150mm, 50x100mm
Wire thickness: 4.0mm,4.5mm,5.0mm
Rigid V: 2, 3, 3, 4, 4, 4, 6
Nos. of brackets 2, 3, 3, 4, 4, 4, 6




Section : SHS
Section size: 50x50, 60x60mm
Height: According to the panel height
Wall thickness: 1.5/2.0/2.5 mm


Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post 1Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post 2



Fence application

1.Muticonstructions, such as properties, companies, gardens, house, etc.
2.Field,such as airoprt, playground, boundary, anti intruder.
3.Protection, such as highway, railway, bridge, etc.
4.Shipping Port Security fencing, Prison security fencing, etc.

Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post 3

Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post 4


Company profile

Anping Yuanmai Wire Mesh Products Co., Ltd. is a professional manufacturer of wire mesh fence, located in Anping County, which is called “the Native land of Wire Mesh” in China. Tailong supplies quality fence and related products for a variety of applications. Our technological expertise and commitment to providing our customers with consistent quality fencing products enable us to become a long term partner for your business.

Commercial 4.0mm 3d Wire Mesh Fence 50x50mm Post 5
