D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM

Place of Origin Hebei
Brand Name Yuanmai
Certification ISO 9001
Model Number YM—01
Minimum Order Quantity 1000pcs
Price $27 -$68/ Piece
Packaging Details Wrapped with shrink film then packed in wood pallet or iron pallet
Delivery Time <20 work days
Payment Terms L/C, T/T
Supply Ability 1800 Set/Sets per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Palisade Fence Feature Easily Assembled,Waterproof,Eco Friendly,Rodent Proof,Rot Proof
Material Steel,Iron,Aluminum Usage Garden Decoration,Home Decration,Back Yard Fence,Protection
Finishing Powder Coated,PVC Coated,Hot Dip Galvanized,hot Dipped Galvanized,Heavy Duty Galvanized Color According To Customer's Request
Post Size 55x100x4.5/5.0mm D/W Pale 2.0mm,2,5mm,3.0mm
Leave a Message
Product Description
Products Description
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 0

Palisade fence pale type

The palisade fence pale can be divided into corrugated pale and angle pale. The corrugated pale has W type and D type with different structure surface.

  • D section pales. Working with long bolts, are designed for boundary delineation requiring low to medium security and damage resistance.
  • W section pales. with higher inherent strength and better vandal resistance, are the most used type to provide effective high security and extra protection. Fastened by short bolts, the W type palisade pales are flush against the horizon rails without flexibility.
  • Angle steel pales. Bolted or welded to horizon fence rails, are suitable for general purpose applications, such as residential estates protection.
Product Paramenters

The common types of palisade fence are W pale and D pale type palisade fencing with three point on the top of the fence. Though the price of the two type is same, but the W pale type palisade fencing is more widely used type than the D pale type, additional, it is more beautiful. So we suggested our customer to choose the W pale type.



Specification Of Palisade Fence
Panel size W section Pale:70mm Angel Rail Post
Height Width Pale Thickness Qty:Pale Cross Rails Square post I Post
1.8m 2.75m 2/2.5/3mm 17pcs 40×40×4mm 60*60mm 100×55mm
2.1m 2.75m 2/2.5/3mm 17pcs 50×50×6mm 80*80mm
2.4m 2.75m 2/2.5/3mm 17pcs   100*100mm
3.0m 2.75m 2/2.5/3/3.5mm 17pcs
W section Pale:62mm
1.8m 2.75m 1.5/2/2.5mm 17pcs 40×40×4mm 60*60mm 100×55mm
2.1m 2.75m 1.5/2/2.5mm 17pcs 50×50×6mm 80*80mm
2.4m 2.75m 1.5/2/2.5mm 17pcs   100*100mm
3.0m 2.75m 1.5/2/2.5mm 17pcs
D Pale section:65mm
1.8m 2.75m 1.5/2/2.5/3mm 17pcs 40×40×4mm 60×60mm 100×55mm
2.1m 2.75m 1.5/2/2.5/3mm 17pcs 50×50×5mm 80x80mm
2.4m 2.75m 1.5/2/2.5/3mm 17pcs   100x100mm
3.0m 2.75m 1.5/2/2.5/3mm 17pcs
Surface treatment: Galvanized or galvanized then powder coating finished
Pale head:Can be do single pointed, triple pointed, square tops, round and notched tops or rounded only.

D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 1
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 2
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 3
Exhibition
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 4
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 5
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 6
Detail
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 7
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 8
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 9
The base material of zinc steel guarderail profile is high temperature hot dipping zinc material, hot dipping zinc refers to the high quality steel into the zinc liquid pool of several thousand degrees, after soaking for a certain time, the zinc liquid will penetrate into the steel, so that it forms a special zinc steel alloy, hot dipping zinc material surface without any treatment in the field environment can reach 30 years without corrosion
Feature
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 10
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 11
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 12
Palisade fence with hot dipped galvanized or PVC coated types is widely used in factories and residences to protect people and properties' safe. Our palisade fencing systems are easily customizable to meet a variety of needs across a wide range of sectors. What’s more, palisade fencing can be combined with products to create the ultimate in protection for facilities requiring anti-ram and anti-vehicle capabilities.
Application
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 13
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 14
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 15
The specific products used in building guardrail are mainly: balcony guardrail, protective window, stair handrail, fence, garden fence, louver, air conditioning fence, road guardrail. Industrial fences (such as factory area fences, commercial site fences), agricultural fences (such as field fences, livestock fences), civil fences (such as building top fences, fence walls, etc.), fences for public facilities (such as road barriers) and so on. It is widely used.
Packing & Delivery
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 16
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 17
Company Profile
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 18
D Pale W Pale Steel Security Metal Palisade Fencing Rot Proof OEM 19
Yuanmai Hardware & Wire Mesh Products Co., Ltd. is a professional manufacturer of wire mesh fences, Our products include chainlink fences, farm fences, SNS protective mesh fences, framework fences, temporary fences, 358 High Security Fences, curvy welded mesh fences, prison fences, airport fences, ornamental fences, iron fences, palisade fences, double loop fences and Euro fences.
Yuanmai also supplies Hesco Bastions, reinforcing mesh, gabions, store cages and decorative wire mesh. Our factory located in Anping County, which is called "the Native land of Wire Mesh" in China.
