2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing

Place of Origin Hebei
Brand Name Yuanmai
Certification ISO 9001
Model Number YM—01
Minimum Order Quantity 1000pcs
Price $27 -$68/ Piece
Packaging Details Wrapped with shrink film then packed in wood pallet or iron pallet
Delivery Time <20 work days
Payment Terms L/C, T/T
Supply Ability 1800 Set/Sets per Week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Palisade Fence Feature Easily Assembled,Waterproof,Eco Friendly,Rodent Proof,Rot Proof
Material Steel,Iron,Aluminum Usage Garden Decoration,Home Decration,Back Yard Fence,Protection
Finishing Powder Coated,PVC Coated,Hot Dip Galvanized,hot Dipped Galvanized,Heavy Duty Galvanized Color According To Customer's Request
Post Size 55x100x4.5/5.0mm D/W Pale 2.0mm,2,5mm,3.0mm
Leave a Message
Product Description
Products Description
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 0
Palisade Fence is available in a choice of head styles, in either type: 'w' or’d’ pale section. D pale is the traditional profile while W pale offers added security to the fencing. Steel palisade fence is manufactured with hot-dipped galvanized steel bar or PVC coated steel bar welded together.
Product Paramenters

Palisade fence is widely used to protect and deter general attack from all types

and conditions of intrusion. The pales are made of hot formed and cold rolled steel belts.These belts offer both strength and rigidity combined with a long life span.Palisade normally produce three types of pales: "W" profile, "D" profile and angle iron type.

Fence panel height
1m-6m
Fence panel width
1m-3m
Pale height
0.5m-6m
Pale width
W pale 65-75mm d pale 65-70mm
Pale thickness
1.5-3.0mm
Angle rail
40mmx40mm 50mmx50mm 63mmx63mm
Angle rail thickness
3mm-6mm
RSJ post
100mmx55mm 100mmx68mm 150mmx75mm
Square post
50mmx50mm 60mmx60mm 75mmx75mm 80mmx80mm
Square post thickness
1.5mm-4.0mm
Straight fishplates or post clamps
30mmx150mmx7mm 40mmx180mmx7mm
Bolts and nuts
M8XNo.34 for pale fixing M12xNo.4 for rail fixing
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 1
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 2
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 3
Exhibition
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 4
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 5
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 6
Detail
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 7
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 8
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 9
The base material of zinc steel guarderail profile is high temperature hot dipping zinc material, hot dipping zinc refers to the high quality steel into the zinc liquid pool of several thousand degrees, after soaking for a certain time, the zinc liquid will penetrate into the steel, so that it forms a special zinc steel alloy, hot dipping zinc material surface without any treatment in the field environment can reach 30 years without corrosion
Feature
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 10
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 11
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 12
The surface of the guardrail is electrostatic sprayed with polyester anti-oxidation powder, which enhances the anti-oxidation, anti-ultraviolet, weather-corrosion resistance. Zinc steel balcony guardrail accessories using the service life of up to 50 years of modified high strength engineering nylon, its strength, hardness is much higher than ordinary steel material, per square meter can withstand more than 183MPA pressure, 2729MPA tensile force, can withstand 220℃ high temperature without deformation and other advantages.
Application
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 13
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 14
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 15
The specific products used in building guardrail are mainly: balcony guardrail, protective window, stair handrail, fence, garden fence, louver, air conditioning fence, road guardrail. Industrial fences (such as factory area fences, commercial site fences), agricultural fences (such as field fences, livestock fences), civil fences (such as building top fences, fence walls, etc.), fences for public facilities (such as road barriers) and so on. It is widely used.
Packing & Delivery
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 16
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 17
Company Profile
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 18
2.0mm 3.0mm Steelway Fence Secure Palisade Galvanised Metal Security Fencing 19
Yuanmai Hardware & Wire Mesh Products Co., Ltd. is a professional manufacturer of wire mesh fences, Our products include chainlink fences, farm fences, SNS protective mesh fences, framework fences, temporary fences, 358 High Security Fences, curvy welded mesh fences, prison fences, airport fences, ornamental fences, iron fences, palisade fences, double loop fences and Euro fences.
Yuanmai also supplies Hesco Bastions, reinforcing mesh, gabions, store cages and decorative wire mesh. Our factory located in Anping County, which is called "the Native land of Wire Mesh" in China.
